When users choose and use induction furnaces, they need to know some knowledge about the configuration methods of power cabinets and furnace bodies.
When users choose and use induction furnaces, they need to know some knowledge about the configuration methods of power cabinets and furnace bodies. Today we will give you a brief introduction.
At present, the common configurations of power cabinet and furnace body are as follows:
1. A set of power cabinet is equipped with a furnace body. This method has the advantages of less investment, small floor area and high efficiency of single furnace body. However, the disadvantage is that there is only one furnace body. After the furnace body heats or melts metal, the furnace body needs to be emptied before the next process can be carried out, resulting in the inability to complete continuous production.
2. One set of power cabinet is equipped with two furnace bodies, one of which is connected to the power supply, and the other is not used temporarily. This method is used to prepare a spare furnace body for the production line. If a furnace body fails and cannot be repaired in a short time, we have at least one spare Plan B available to maintain the capacity as much as possible.
3. One set of power cabinet is equipped with two furnace bodies, both of which should be connected to the power supply. One furnace body is fixed for smelting, and the other furnace body is fixed for thermal insulation. This method is suitable for long pouring time. The molten steel after smelting needs to be kept at the temperature in the furnace for a period of time, so the method of one melting and one heat preservation is adopted, so that both furnace bodies can be fully utilized.
4. One set of power supply cabinet is equipped with two furnace bodies, both of which should be connected to the power supply. At the same time, we can choose a high-performance furnace change switch between the two furnace bodies to make the furnace change more convenient. With this method, the two furnace bodies can work in rotation, switch smelting and heat preservation functions at any time, and serve as backup for each other. Even if the furnace lining is changed, the production will not be affected. This is the most convenient way, but the cost will also increase.
Of course, these are just our suggestions. The power supply and furnace body should be configured according to the actual production situation of users.
